Pneumatic Paddy Husker

Product properties
  • Summary:1. Convenience in operation.
    2. Easy and simple in adjustment.
    3. Large capacity, low broken, high efficiency.
    4. Low noise and no oil leak, convenient for rice cleaning.
    5. Smooth transmission and stable performance
    6. It uses vertical air suction duct when separating paddy shell.

Pneumatic Paddy Husker Introduction:
It uses a pair of rubber roles which rotate in opposite direction and husk the paddy shell. The paddy husk and the brown rice will be separated by the husk separator.


Pneumatic Paddy Husker Characteristics:
1. It utomaticly controls the motion sequence of equipments to realize tightening rollers when paddy feeding and loosening. It is convenience in operation.
2. Lineal control of tightening pressure between rolls with barometer,digital-regulated display of feeding volume. It is easy and simple in adjustment.
3. Large capacity, low broken, high efficiency.
4. It uses synchronous belt transmission without gear box, low noise and no oil leak, convenient for rice cleaning.
5. Smooth transmission and stable performance
6. It uses vertical air suction duct when separating paddy shell.


Technical Parameter:
Model
MLGQ25B
MLGQ36
MLGQ51
Capacity
3-5t/h
4-6 t/h
6-10 t/h
Power
7.5kW
11 kW
15 kW
Wind Volume
3400-3700 m3/h
4000-4500m3/h
6800-7400m3/h
Rubber Roller Size(diameter×length)mm
254×254
225×356
254×508
Weight(kg)
700
1000
1300
